| Place of Origin: | CHINA |
| Brand Name: | SAER |
| Certification: | CE CERTIFICATE |
| Model Number: | CSR 2200 |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiation |
| Packaging Details: | without fumigation wooden package |
| Delivery Time: | 5-8 DAYS AFTER PAYMENT |
| Payment Terms: | T/T |
| Supply Ability: | 1000 sets / month |
| Type: | Inkjet Printer | RAM: | 128M |
|---|---|---|---|
| Automatic Grade: | Automatic | Warranty: | 1 Year |
| Keywords: | Sublimation Machine | Product Name: | Sublimation Textile Heat Transfer Printer |
| Feature: | High Speed | Ink: | Pigment Ink Sublimation Ink |
| Print Head: | Epson High Presicion | Resolution: | 1800DPI |
| Plate Type: | Digital Printing,Textile Printer,Roll To Roll | Ink Type: | Sublimation Ink |
| Color: | 4 Colors (CMYK) | ||
| High Light: | sublimation printing machine,digital textile printing equipment,cmyk printing machine |
||
| Product name | Economic CSR2200 Sublimation Machine | ||
| Item No. | CSR 2200 | ||
| Printhead | EPSON | ||
| Number of Printhead | Three | ||
| Print Resolution | 1800dpi | ||
| ink | sublimation ink/pigment ink. | ||
| Maximum Print Width | 2000mm | ||
| Print Speed | 3 pass | 360x1800DPI | 65m²/h |
| 4 pass | 720X1200DPI | 45m²/h | |
| 6 pass | 720x1800DPI | 35m²/h | |
| Printer Head height | Adjustable 1.5~6mm | ||
| Ink | Type | Sublimation Ink, pigment ink | |
| Color | dual CMYK | ||
| Ink Supply System | Continuous Ink Supply System | ||
| Media | Maximum Width | 2000mm | |
| Feeding mode | Automatic feeding and taken-up system | ||
| weight | Sublimation machine net weight 800kg, gross weight 1000kg | ||
| power consumption | sublimation heater | Directly dye sublimation heater 3500w | |
| printer | printer 1000w | ||
| printer power | AC210-230v | 50-60HZ 16A | |
| temperature | 25-35°C | ||
| humidity | 35-65%(non-condensing) | ||
This machine prints directly on fabric without heating transfer process.
It can work continuously for 24 hours without corrugated.
1. Stable and continuous printing, using strong mechanical to ensure printing high resolution and stabilitIty
2.Adopt professional feeding system and fit to textile without tension.
Stable feed resolution and stability material, make sure printing process
3. No need platemaking and fit to flag and scroll
4. Using constant temperature coloration box, fast temperature rising. Good tightness to guarantee the even temperature
5. Environmental smoke exhaust filter system to handle smoke efficiently and make clean work shop
6. Use open ink supply system which is compatible to more brand sublimation ink
1. Constant temperature heating box
rapidly heating, good leakproofness ensure the temperature constant
2. Green smoke extraction filtration system
filter and sublimation smoke efficiently, keep the environment clean
3. open ink-supply system
Compatible with many brands of sublimation ink, easily to control the printing cost.
1. With one year warranty and lifelong technical support.
2. Offer Video and operation manual, and the professional technical staff online guidance.
3. Guarantee prompt warranty service for main parts repairmen and replacement by international courier
