CMYK Four Colour Epson Head Digital Fabric Printing Machine

CMYK Four Colour Epson Head Digital Fabric Printing Machine

    • CMYK Four Colour Epson Head Digital Fabric Printing Machine
    • CMYK Four Colour Epson Head Digital Fabric Printing Machine
  • CMYK Four Colour Epson Head Digital Fabric Printing Machine

    Product Details:

    Place of Origin: Shanghai Of China(Mainland0
    Brand Name: SAER
    Certification: CE
    Model Number: CSR 3200

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set
    Price: Negotiation
    Packaging Details: Non Fumigation Wooden Package(4.56X1.18X1.56M)
    Delivery Time: 7 working days after receive your payment
    Payment Terms: T/T
    Supply Ability: 100 Sets / Month
    Contact Now
    Detailed Product Description
    Maximum Media Width: 3.3 Meter Color & Page: Multicolor
    Color Mode: Double 4 Color(Cyan,Magenta,Yellow,Black) Voltage: 380V
    Gross Power: 5.5KW Print Head: Epson DX5 * 2 Pcs
    Plate Type: Sublimation Textile Printer Compatible OS: Windows XP & Windows 7
    Combine With: One 3.2m All-in-one Printing System And One Filter Ink: Sublimation,Reactive,Pigment Ink
    Material: Polyester,Cotton,Silk,linen And Wool Fabric Or Mixed Fabric Weight: 1120kg
    Rip Software: Onyx Work Type: Computer Directly Control Output

    CMYK Four Colour Epson Head Digital Fabric Printing Machine





    Product Description:

    Combined with 3.2m all-in-one printing system and filter fan,directly sublimation printing type,printed material can use indoor and outdoor,can stand sunshine and no fade,Colour fastness grade IV.also can be washed.



    Usage:



    Serve solutions for small production, sample making ,designer ideas and training areas .



    Specifications



    Model

    CSR3200

    Printhead Technology

    Piezo Inkjet

    Print Head Epson DX5

    Ink Type

    Diperse Dye Ink,reactive ink,pigment ink

    Color Mode

    4 color(Cyan,Magenta,Yellow,Black)

    Nozzles

    (180 nozzles*8 lines)*2 heads

    Print Head Height

    1.5mm / 6mm(adjustable)

    Ink Supply Mode

    Continuous Ink Supply

    Max Media Width

    3300mm



    Max Printing Width

    3200mm

    Printing Resolution And Speed

    Resolution(DPI)          Speed

    720*360dpi(2 pass)      40m2/h

    360*1080dpi(3 pass)     32m2/h

    720*720dpi(4 pass)      22m2/h

    720*1080dpi(6 pass)     18m2/h

    720*1440dpi(8 pass)     12m2/h

    Roll Owter Diameter

    3 Inch

    Max Weight For Roll Material

    100KG

    Interface

    USB 2.0

    RAM

    128M

    Printer Power

    380V

    Power

    Direct Dye Sublimation Heater 3500W

    Printer                       2000W

    Environment

    temperature    20-32 degree

    Weight

    1120KG



    Working Steps:



    Digital inkjet printing is take advantage of scanner, digital camera or the Internet,digitizing the required picture pattern,and then fed into computer.

    after the computer printing color separation system editing, combination, draft processing,and then use dedicated software driver chip to control the printing system,
    the special dye ink will be directly printed on variety of pretreated textiles or fabrics and other media,with drying to fix the color,washing and finishing to obtain the required exquisite printing products.





                                                                             CSR 3200

    Features:



    1.Double Epson DX5 Print heads, faster speed, longer head life time. Feather printing function available, print heads correction and counterpoint are more easy.

    2.Using HIWIN mute guide rail. Germany IGUS silent drag chain make your printing environment more quiet

    3.X axis and Y axis are using AC servo motors.

    4.Intelligent print head cleaning service, supplys safe and convenient print head cleaning and protection function.

    5.Equipped with the feeding motor Positive and Negative transfer function, taking and feeding constant tension transmission system.

    6. The unique print platform design to make the cloth always smooth in the process of printing.

    7. Unique filtering lampblack system, make the picture very clean.

    8. Taking up and feeding roller are inflatable roller.

    9. Taking up and feeding fabric are smoothly

    10. Low cost and no need any transfer paper.



    CMYK Four Colour Epson Head Digital Fabric Printing Machine



    Rip Software:

    1. Easy to complete the Photos / vector data,replacement of RGB / CMYK,and can easily to achieve color change.
    2.Colorful color replacement function can easily reproduce the required color.

    CMYK Four Colour Epson Head Digital Fabric Printing Machine

    Advantages:



    Save Money                       No need to use transfer paper

    Save Time                          No need to perform heat transfer step

    Save Space                        No need to keep a workplace for a heat transfer machine

    • Suitable for small lot, Personality, Diversity Printing, Without Limit Of Quantity.
    • The printed image color is bright and vivid with nice color gamut.
    • Rapid speed and various printer to choose
    • It is simple and leave out heat transfer process, one person can operates with high efficency and short time.
    • Low cost and no need of any kind transfer paper, liner breaking the highest costs performance
    • Printed image color is bright and vivid to meet high quality printing equipment

    Applications:



    Interior Home Decoration: Print on polyester fabric to make windows curtain and Tablecloth, sheets and so on.

    Outside: Advertising materials to make flag, banner, act fast show and so on.



    Available Ink and Material:



    1) Sublimation Ink (water based): mainly used in polyester fabric.

    Completed fabric can use to make all kinds of flags,banner shows and for home decoration

    2) Reactive Ink:For cotton,linen and silk etc.

    After printing and heating,the materials can use to make clothes and scarf.

    3) Pigment Ink:For all kinds of textile fabrics.



    CMYK Four Colour Epson Head Digital Fabric Printing Machine



    How To Order:



    Inquriy-------Quotation-------Order-------Production-------Quality Control-------Packing-------Shipping-------Delivery



    CMYK Four Colour Epson Head Digital Fabric Printing Machine



    After Sales Service:



    1. With one year warranty and lifelong technical support.

    2. Offer Video and operation manual, and the professional technical staff online guidance.

    3.  Guarantee prompt warranty service for main parts repairment and replacement by international courier
