Large Size Heat Sublimation Machine Automatic Multi Color Dual CMYK

Large Size Heat Sublimation Machine Automatic Multi Color Dual CMYK

Large Image :  Large Size Heat Sublimation Machine Automatic Multi Color Dual CMYK

Verified Supplier

Shanghai of China

Verified Supplier

Shanghai of China

Detailed Product Description
Plate Type: Sublimation Oven Automatic Grade: Automatic
Condition: New Color & Page: Multicolor
Dimensions(L*W*H): 4350mm*1310mm*1230mm Usage: Textile Color Fixation Machine
Working Width: 3.2m Color Mode: Dual CMYK
Take Up Working Method: Directly Out Or Roll To Roll Gross Weight: 680kg
High Light:

sublimation oven

,

printing dryer

,

textile printing machines

3.2m Large Size Heat Sublimation Machine Automaticly Multicolor Dual CMYK





Products Features



1. Far infrared blackbody tube radiation electro thermal heating,our tube can work at least 10000 hours.

2. Our machine have excellent heat insulation,can save more power for you.

3. Easy to load the media in and out oven during your machine working

4. Blackbody tube have more thermal efficiency

5. Intelligent PID Temperature Control

6. Feeding and Taking up Are synchronous
7. Perfect oil & water collect solution in oven..

8. Quick Tail Gas Treatment
9. Convenient to Maintain
10. Easy to Set up and Operate

11. Easy to open the caver to clean inside of oven
12. Easy to change the active carbon from the filter

13. Perfect heat insulation,can touch our machine without danger of scald



Adopting the most advanced thermal energy technology low power consumption,saves electricity and conserve energy costs.



Specifications



Product Name

Direct Dye Sublimation machine

Model

SR 3200

Blackbody Tube Working Model

Far Infrared

Mainly Use

Appear and fix the color

Power

6.5kw(include filter fan)

Maximum Width

3300mm

Heat Tube Dimension

3400mm

Working Temperature Control

Room temperature ~250°C

Temperature Control Method

PID

Tension Control

3kg(optional counterweight to control tension)

Maximum Speed

0~2800mm/min

Filter Fan Speed

0~300m³/h

Filter Fan Power

400W

Working Voltage

220v 50hz

Machine size

4350mm*1310mm*1230mm(not include filter

Net Weight

625kg(not include filter)

Gross Weight

1025kg(Include filter and package)

Operating mode

Instrument control, manual, automatic opera



Advantage



1. Exhaust without any smell, good environment need.
2. Normal temperture for exhaust , no dangerouse for hot air out.
3. High Efficiency cold system to make sure the exhaust temperture less then 25 Degree.
4. Drawer-type device in a timely manner to facilitate the replacement of activated carbon to ensure that the emission of harmful gases.

5. Can united any piezo printers



Large Size Heat Sublimation Machine Automatic Multi Color Dual CMYK 0

Applications



Interior Home Decoration:Print on polyster fabric to make windows curtain and Tablecloth,sheets and so on.

Outside:Advertising materials to make flag,banner,act fast show and so on.



After Sales Service



1. With one year warranty and lifelong technical support.

2. Offer Video and operation manul,and the professional technical staff online guidance.

3. Guarantee prompt warranty service for main parts repairment and replacement by international courier
