Directly Automatic Digital Fabric Printing Machine 380V Voltage 6500W Power

Directly Automatic Digital Fabric Printing Machine 380V Voltage 6500W Power

    • Directly Automatic Digital Fabric Printing Machine 380V Voltage 6500W Power
    • Directly Automatic Digital Fabric Printing Machine 380V Voltage 6500W Power
  • Directly Automatic Digital Fabric Printing Machine 380V Voltage 6500W Power

    Product Details:

    Place of Origin: Shanghai Of China
    Brand Name: SAER
    Certification: CE
    Model Number: CSR 3200

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Non Fumigation Wooden Package(4460*1160*1730mm)
    Delivery Time: 10 working days after receive your payment
    Payment Terms: T/T or Western Union
    Supply Ability: 20 sets / month
    Contact Now
    Detailed Product Description
    Product Name: Digital Fabric Printing Machine Application: Indoor & Outdoor Advertising Field
    Color & Page: Multicolor Color Mode: Dual CMYK(Cyan,Megenta,Yellow,Black)
    Voltage: 380V Print Head: Epson 4720 * 3
    Rip Software: Maintop 5.3 Rip Software Or Neostampa 8 Optional Compatible OS: Windows XP & Windows 7
    Include: One 3.2m All-in-one Printing System And One Filter Ink: Sublimation,Reactive,Pigment Ink
    Material: Polyster,Cotton,Silk And Wool Coated Fabric Gross Power: 6500W

    Directly Automotic Digital Fabric Printing Machine For Home decoration





    Specifications



    Model

    CSR3200

    Print head

    Piezo technology, Epson 4720 print head

    Ink

    Sublimation Ink,Reactive ink and Pigment Ink

    Color Mode

    Dual CMYK(Cyan,Megenta,Yellow,Black)

    Nozzles

    (180 nozzles*8 lines)*3 heads

    Print Head Height

    1.5mm/6mm(adjustable)

    Ink Supply Mode

    Continuous Ink Supply

    Max Material Width

    3300mm



    Max Printing Width

    3200mm

    Printing Resolution And Speed

    Resolution(DPI)          Speed

    720*360dpi(2 pass)      40sqm/h

    360*1080dpi(3 pass)     32sqm/h

    720*720dpi(4 pass)      22sqm/h

    720*1080dpi(6 pass)     18sqm/h

    720*1440dpi(8 pass)     12sqm/h

    Roll Owter Diameter

    3 Inch

    Max Weight For Roll Material

    100KG

    Interface

    USB 2.0

    RAM

    128M

    Printer Power

    380V

    Power

    Direct Dye Sublimation Heater 3500W

    Printer                       2000W

    Environment

    temperature    20-32 degree

    Weight

    1120KG



    Features:



    Printer:



    1. Double Origimal Epson DX7 print head, with fast print speed, long lifespan, and high precision.

    2. Printing groove designed specially for fabric printing to collect waste ink and keep fabric clean.

    3. HIWIN mute guide rail,Germany IGUS silent drag chain,make the printing environment quieter.

    4. Refillable ink cartridge reduces production cost.



    Heater:



    1. Ceramic heating tube: Heating fast and well distributed

    2.Feeding and taking up inflatable roller.

    3. Front and back stainless steel oscillating axles make the fabric feeding smoothly without drape.

    4. Intelligent Temperature control system. (0°C----300°C adjustable)

    5. Discharge slot design helps to keep the heating tube clean and easy to wipe off the oil and dust.



    Directly Automatic Digital Fabric Printing Machine 380V Voltage 6500W Power



    Filter:



    1.  Exhaust pipes fully discharge the smoke from the tube.

    2.  Carbon can be inputted easily, it makes the environment odorless and smokeless.

    3.  Discharge slot is easily to clean.



    Directly Automatic Digital Fabric Printing Machine 380V Voltage 6500W Power

    Applications:



    Interior Home Decoration: Print on polyester fabric to make windows curtain and Tablecloth, sheets and so on.

    Outside: Advertising materials to make flag,roll up banner, act fast show and so on



    After Sales Service:



    1. With one year warranty and lifelong technical support.

    2. Offer Video and operation manual, and the professional technical staff online guidance.

    3. Guarantee prompt warranty service for main parts repairment and replacement by international courier
