100% Polyester Sublimation Flag Printing Machine Dual CMYK Color Easy Operation

100% Polyester Sublimation Flag Printing Machine Dual CMYK Color Easy Operation

    • 100% Polyester Sublimation Flag Printing Machine Dual CMYK Color Easy Operation
    • 100% Polyester Sublimation Flag Printing Machine Dual CMYK Color Easy Operation
  • 100% Polyester Sublimation Flag Printing Machine Dual CMYK Color Easy Operation

    Product Details:

    Place of Origin: Shanghai of China
    Brand Name: SAER
    Certification: CE Certification
    Model Number: CSR3200

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Non fumigation wooden package
    Delivery Time: 14 days after get the payment
    Payment Terms: T/T, Western Union
    Supply Ability: 100 sets per month
    Contact Now
    Detailed Product Description
    Plate Type: Roll To Roll Type: Digital Printer
    Automatic Grade: Automatic Color & Page: Multicolor
    Usage: Fabric Printing Material: All Kinds Of Fabric Without Elastic
    Color Model: Dual CMYK

    Product name: 100% polyester fabric printer / feather flags printing machine / Sublimation Flag Printing Machine





    Product features:



    1. Far Infrared Blackbody Tube Radiation Electro thermal Heating, our tuble can work at least 10000 hours.




    2. Our machine have excellent heat insulation, can save more power for you.




    3. Easy to load the media in and out oven during your machine working




    4. Blackbody tuble have more thermal efficiency





    5. Intelligent PID Temperature Control





    6. Feeding and Taking up Are synchronous




    7. Taking up can choose roll to roll .







    8. Quick Tail Gas Treatment




    9. Convenient to Maintain




    10. Easy to Set up and Operate





    11. Easy to open the caver to clean inside of oven




    12. Easy to change the active carbon from the filter











    Adopting the most advanced thermal energy technology low power consumption, saves electricity and conserve energy costs.





    Specification:



    Product parameter
    Product name Sulimation textile printing system
    Model CSR3200
    Include One set of whole machine and one filter
    Ink model Sublimation ink
    Available color Dual CMYK
    Print head Piezo technology,3 Epson 4720 print head
    Max material width 3300mm
    Max printing width 3200mm
    Print head high control 1.5mm/1.6mm(adjustable)
    Printing resolution and speed Resolution(DPI)                  Speed
    360*1800dpi(3 pass)          65m2/h
    720*120dpi(4 pass)            45m2/h
    720*1800dpi(6 pass)          35m2/h
    Media type Polyester
    Ink feeding system 4 color  mode:400cc  cartriage*2color  800cc/color
    Roll outer diameter 3 inch
    Max weight for roll material 100kg
    Head cleaning Automatic/Manual
    RAM 128M
    Printer power AC380V(Adaptive)  50/60Hz±1Hz
    Heater power consuption 3500KW
    Printer power consuption 7.5KW
    Weight 890KG
    Operation environment 20-23oC   Humidity:40-60% (non-condensing)



    Filter Specification:



    Power 550w
    Package size 60*55*108CM(0.382CBM)
    Net Weight 64kg
    Gross Weight 80kg
    Working Voltage 220-240V 50HZ
    Input Air Temperature ﹥200℃
    Out Air Temperature ﹤25℃



    Warranty & Services:

    (1) One year of warranty time.
    (2) About the after-sales service:
    A. If the printer has problem, the client can take a picture or video to the technician.
    B. The technician will teach the client to fix and operate the printer through the internet.
    C.We will ask the client to send back the board which is wrong to check it.
    D.The technician is full of experience, and the sales also keep in touch with the client.
