Shanghai Color Digital Supplier Co., Ltd.
Professional Digital Textile Printing Equipment & Relevant Materials General Supplier
 |
| Place of Origin: | Shanghai,China |
| Brand Name: | SAER |
| Certification: | CE |
| Model Number: | CSR 3200 |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Non fumigation wooden package |
| Delivery Time: | 10 working days after get your payment |
| Payment Terms: | 100% T/T in advance |
| Supply Ability: | 50 sets per month |
| Application: | Indoor Decoration & Outdoor Advertisement ` | Resolution: | 360dpi Minimum And 1800dpi Maximum |
|---|---|---|---|
| Voltage: | 380V,50 / 60HZ | Print Head Type: | Two / Four Kyocera Print Head |
| Rip Software: | Onyx | Compatible OS: | Win 7 & Win 10 |
| Working Type: | Computer Directly Control Output | Combine With: | All-in-one Printer And One Filter Fan |
| Ink Supply Mode: | Continuous Supply | Ink Supply Mode: | Continous Ink Supply |
| Ink Type: | Sublimation And Pigment Ink | ||
| High Light: | Decoration Fabric Cutting Plotter,Advertisement Fabric Plotter,Plotter Fabric Printing Equipment |
||
Product name : Printing Equipment Manufacture Printer with 4 Heads for Fabric
Contents:
One 3.2m impartible textile printing system(print and heat synchronously)
One filter fan for pollute waste air protect the environment.
Usage:
Directly print on roll textile material,after the step of print,through high temperature of heating,the completed fabric can directly to make every kinds of flags,and for home decoration,the fabric can stand sunshine and can wash,no fade.
Technical Detais:
| Product Name | Digital Textile Flag Printing Machine | |||||||
| Model | CSR3200 | |||||||
| Combine With | impartible Printing system and one Filter Fan | |||||||
| Print head | Piezo technology,Epson head | |||||||
| Ink | Sublimation ink,Reactive ink,Pigment ink | |||||||
| Media Type | Polyester,Cotton,Linen,Silk,Wool etc | |||||||
| Color mode | Dual CMYK | |||||||
| Nozzles | (400nozzles*8lines)*4 heads | |||||||
| Print head higher | Adjustable | |||||||
| Ink supply mode | 4 color mode:400cc cartridge*2/ color 800cc / color | |||||||
| Max meterials width | 3300mm | |||||||
| Max printing width | 3200mm | |||||||
| Printing resolution and speed | Resolution | speed | ||||||
| 360*1800dpi (3 pass) | 80m2/h | |||||||
| 720*1220dpi (4 pass) | 65m2/h | |||||||
| 720*1800dpi (6 pass) | 45m2/h | |||||||
| Roll owter diameter | 3 Inch | |||||||
| Max weight for roll materials | 100kg | |||||||
| Printer Power | AC220-240V(Adaptive).50 / 60Hz±1Hz | |||||||
| Sublimation heater power | AC380V.30A | |||||||
| Printer Power consumtion | 1.5KW | |||||||
| Heater Power consumtion | 8kw | |||||||
| Environment | Temperature:20-32℃ | |||||||
| Humidity:40-60℃(Non-condensing) | ||||||||
| Weight | 2000kg | |||||||
| Rip Software | Onyx Optional | |||||||
| Compatible OS | Win XP & Win 7 | |||||||
Onyx Rip Software:
1. Easy to complete the Photos / vector data,replacement of RGB / CMYK,and can easily to achieve color change.
2.Colorful color replacement function can easily reproduce the required color.
Available Ink and Material:
1) Sublimation Ink (water based): mainly used in polyester fabric.
Completed fabric can use to make all kinds of flags,banner shows and for home decoration
2) Reactive Ink:For cotton,linen and silk etc.
After printing and heating,the materials can use to make clothes and scarf.
3) Pigment Ink:For all kinds of textile fabrics.
Specifications:
1. Low cost
2. High productivity
3. Dye Sublimation system
4. Directly print on textile material
Save Money No need to use transfer paper
Save Time No need to perform heat transfer step
Save Space No need to keep a workplace for a heat transfer
Description:
Speed and precision perfectly reflected
With 1800 DPI highest precision and 120 sqm/hour fastest speed
Adopt high speed industrial KYOCERA printhead
X-ais use liner motion motor and magnetic grating
Y-axis use Fuji AC servo motor
Applications:
Interior Home Decoration: Print on polyester fabric to make windows curtain and Tablecloth, sheets and so on.
Outside: Advertising materials to make flag, banner, act fast show and so on.
After Sales Service:
1. With one year warranty and lifelong technical support.
2. Offer Video and operation manul,and the professional technical staff online guidance.
3. Guarantee prompt warranty service for main parts repairment and replacement by international courier
How To Order:
Inquriy-------Quotation-------Order-------Production-------Quality Control-------Packing-------Shipping-------Delivery
