  • Product Details

Automatic Dtg Garment Printer / Digital Garment Printing Machines CE

Verified Supplier

CHINA

Detailed Product Description
Condition: New Automatic Grade: Automatic
Ink Type: Pigment Ink Type: Inkjet Printer,T Shirt Flatbed Printered
Warranty: 1 Year Color: C.M.Y.K.+W
After-sales Service Provided: Engineers Available To Service Machinery Overseas Product Name: Digital Printing Apparel Textile Flatbed Laser Cutting Machinery
High Light:

t shirt screen printing machine

,

garment printing machine


t Shirt printing T-Shirt Printing Machines Fabric Printers for DTG Printing


High speed T shirt printing machine with 8 ricoh nozzle, can print different color , three station design, support multi-version delivery, work efficiency.
Imported paint ink, soft feel and high color fastness co exist.Customized professional Rip software, picture looks more three-dimensional.
Automatic Dtg Garment Printer / Digital Garment Printing Machines CE 0
1. printing surface can print 600*1200.
2.head can lift by 6 cm.Can replace by any size table
3.The spacing between printing nozzle and cloth can maintain a height of 10mm.With the addition of a head-mounted collider, the spacing can greatly reduce the risk of rubbing against the head of the nozzle
4.with high viscosity of ink resin, high fastness of printed pattern.The ink is smooth and not easy to plug
5. can be printed in cycles, saving the waiting time of manual laying.
6.Printing speed of output A3 format printing time is 1 minute 50.
7. black cloth background color gradient layer is good, do not show white color.Ensure the breathability of fabric after printing.
8. White ink cycle can reduce white ink precipitation, prevent the bubbles in the ink from affecting the printing line.
9.Double guide rail machine is more stable and firm.



Automatic Dtg Garment Printer / Digital Garment Printing Machines CE 1
Automatic Dtg Garment Printer / Digital Garment Printing Machines CE 2
t shirt printers printing machine specifications

Items Technical Parameters
Model CSR2200(R)
Print head Print head Ricoh GH2220 head
QTY 8
Ink Color CMYK+WWWW/CMYK+FMFY+WW/CMYK+OR BL+WW
Ink type Import pigment ink, good fastness,bright color
Ink supply Negative pressure supply ink
Speed Production A3 size 4pass Dark fabric 1min14s
Light fabric 58s
precision A3 size 6pass Dark fabric 1min52s
Light fabric 1min27s
Tray Standard configulation Optional configulation
Tray size 380*480mm 600*1200mm
Tray Numbers 3 1
Interface USB
Computer system CPU>2GHz, 64 bit CPU, RAM>8G, Windows7,Windows10
Working environment temperature:20℃-30℃, humidity:55%-70%
Power supply 210-230VAC 50/60 HZ 16A
Software Rip software
Machine Dimension 2065*1705*1240mm
Machine Weight 260kg






  Shanghai Color Digital Supplier has been established 2001, it's advanced professional digital printing equipment & relevant materials general supplier. From 2004 we paid most costs and energy to R &D Sublimation system and relevant equipment and consumables.
   Now we have been launched SR series product successfully. Sublimation system sometimes we like called heat transfer system, now our produces have been used most field such as advertisement printing textile digital printing , carpet digital printing, windows curtain digital printing and interior decoration printing and Flax printing widely.
Automatic Dtg Garment Printer / Digital Garment Printing Machines CE 3


company CE certificate




Automatic Dtg Garment Printer / Digital Garment Printing Machines CE 4






You’re committed to your business, and so are we - your success is our success, after all. That’s why you can count on our top-notch staff to deliver high quality service, from your first question to your final edit.
