Digital T Shirt Printing Machine Direct To Garment Printer With 8 RICOH Print Heads

Digital T Shirt Printing Machine Direct To Garment Printer With 8 RICOH Print Heads

    • Digital T Shirt Printing Machine Direct To Garment Printer With 8 RICOH Print Heads
    • Digital T Shirt Printing Machine Direct To Garment Printer With 8 RICOH Print Heads
  • Digital T Shirt Printing Machine Direct To Garment Printer With 8 RICOH Print Heads

    Product Details:

    Place of Origin: China
    Brand Name: SAER
    Certification: CE Certification
    Model Number: CSR2200(R)

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 14,000usd-15,000usd
    Packaging Details: Non-fumigation wooden box
    Delivery Time: withion one week workdays after get the payment
    Payment Terms: Western Union, T/T
    Supply Ability: 100 per month
    Contact Now
    Detailed Product Description
    Max DPI: 1200*1800 Place Of Origin: Shanghai , China
    Ink Type: CMYK+WWWW/CMYK+FMFY+WW/CMYK+OR BL+WW Condition: New
    Media Type: Fabric Automatic Grade: Automatic
    Warranty: 1 Year Brand Name: SAER

    Product name2019 Hot-selling A3 size digital T-shirt printer direct to garment printer with 8 RICOH print heads




    Machine Features:





    a. Satisfied ink density and saturation



    b. Color channel adjustable, help you to extent the working life of your print head together with printer.



    c. Control software could close the nozzle which cloged,then it could print a perfectly printings.And the heads distance feather function could cover the heads distance on physical position.



    d. One of the best boards control system have been tested on our printer,and more than 72 hours tested before shipping.guarantee the best quality.



    e.Auto alarming system for ink and material lack.Ink pump pressure adjustable,easier to clean print head or pump ink,save ink and your time








     Working Speed:




    Speed Production models A3 size 4pass Dark color fabric 1min.14s
    Light color fabric 58s
    precision A3 size 6pass Dark color fabric 1min.52s
    Light color fabric 1min.27s





     Tray situation:


    Tray Standard configuration Optional configuration
    Tray size 380*480mm 600*1200mm
    Tray Numbers 3 1







      Specificaiton:




    Items Technical Parameters
    Model

    CSR2200(R)

    Print head Print head Ricoh GH2220 head
    QTY 8 pieces
    Ink Color CMYK+WWWW/CMYK+FMFY+WW/CMYK+OR BL+WW
    Ink type Import pigment ink, good fastness,bright color
    Ink supply Negative pressure supply ink
    Interface USB
    Computer system CPU>2GHz, 64 bit CPU, RAM>8G, Windows7,Windows10
    Working environment temperature:20℃-30℃, humidity:55%-70%
    Power supply 210-230VAC 50/60 HZ 16A
    Software Rip software
    Machine Dimension 2065*1705*1240mm
    Machine Weight 260kg




    Operation mode :


    1. Upload pictures to computers

    Upload the required pictures to the computer software and arrange them neatly in the software .



          2.Location of clothes



    Fixed and arranged the samples needed to be typed on the machine.



         3. Start printing



    Click on the button to start printing,wait for more than one minute ,print successfully,effect display.





    Printed Samples:


    Digital T Shirt Printing Machine Direct To Garment Printer With 8 RICOH Print Heads
    Digital T Shirt Printing Machine Direct To Garment Printer With 8 RICOH Print Heads








    After-sale service



    We can offer online english service by our skillful and experienced technicians,online guide with camera & microphone to help you and your clients.

    We have detailed record the videos of how to maintain the machine to the User manual .

    We will keep on providing the best service,beause your satisfation is our pursuit.
