Shanghai Color Digital Supplier Co., Ltd.
Professional Digital Textile Printing Equipment & Relevant Materials General Supplier
 |
| Place of Origin: | Shanghai of China |
| Brand Name: | SAER |
| Certification: | CE |
| Model Number: | CSR 3200KJ |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Non fumigation wooden package |
| Delivery Time: | 10 working days after get your payment |
| Payment Terms: | T/T |
| Supply Ability: | 50 sets / month |
| Application: | Indoor Decoration | Resolution: | 1800dpi Maximum |
|---|---|---|---|
| Color Mode: | Dual CMYK | Voltage: | 380V,50/60HZ |
| Print Head Type: | Kyocera Print Head(two Or Four Optional) | Rip Software: | Onyx |
| Working Type: | Computer Directly Control Output | Combine With: | All-in-one Printer And One Filter Fan |
| Ink Supply Mode: | 4color Mode:400cc Cartridge*2/color 800cc/color | Ink Supply Mode: | Continous Ink Supply |
| Print Speed: | 60sqm/hour In 4 Pass | Max Speed: | 120sqm / Hour |
| High Light: | sublimation printing machine,cmyk printing machine |
||
High Speed Industrial Digital Textile Printer Use Waterbased Pigment Ink
Consist of:
One 3.2m all-in-one direct textile printing system(print and heat at the same time)
One filter fan for pollute waste air,protect the environment.
Usage:
Directly use pigment ink print on roll textile material(cotton,silk,wool etc),then through high temperature of heating to dry the wet ink,the completed fabric can directly to make every kinds of products,like wall fabric,curtain,table cover and bed sheets,the fabric can stand sunshine and can wash,no fade.
Technical Detais:
| Product Name | Digital Textile Printing Machine | |||||||
| Model | CSR3200KJ | |||||||
| Combine With | 3.2m All-in-one Printing system with one Filter Fan | |||||||
| Print head | Piezo technology,Two / four KYOCERA print heads | |||||||
| Ink | Pigment ink | |||||||
| Media Type | Cotton,Linen,Silk,Wool etc | |||||||
| Color mode | Dual CMYK | |||||||
| Nozzles | (180nozzles*8lines)*2 /4 heads | |||||||
| Print head higher | Adjustable | |||||||
| Ink supply mode | 4color mode:400cc cartridge*2/color 800cc/color | |||||||
| Max meterials width | 3300mm | |||||||
| Max printing width | 3200mm | |||||||
| Printing resolution and speed | Resolution | speed | ||||||
| 600*600dpi 2pass | 120㎡/h | |||||||
| 600*600dpi 3pass | 60㎡/h | |||||||
| 600*900DPI(3 pass) | 75㎡/h | |||||||
| 600*1200dpi 4pass | 48㎡/h | |||||||
| 720*1080dpi 6pass | 30㎡/h | |||||||
| Roll owter diameter | 3 Inch | |||||||
| Max weight for roll materials | 100kg | |||||||
| Printer Power | AC220-240V(Adaptive).50/60Hz±1Hz | |||||||
| Sublimation heater power | AC380V.30A | |||||||
| Printer Power consumtion | 1500W | |||||||
| Heater Power consumtion | 8kw | |||||||
| Environment | Temperature:20-32℃ | |||||||
| Humidity:40-60℃(Non-condensing) | ||||||||
| Weight | 2000kg | |||||||
| Rip Software | Onyx | |||||||
| Compatible OS | Win XP & Win 7 | |||||||
 |
 |
 |
Onyx Rip Software:
1. Easy to complete the Photos / vector data,replacement of RGB / CMYK,and can easily to achieve color change.
2.Colorful color replacement function can easily reproduce the required color.
Available Ink and Material:
1) Sublimation Ink (water based): mainly used in polyester fabric.
Completed fabric can use to make all kinds of flags,banner shows and for home decoration
2) Reactive Ink:For cotton,linen and silk etc.
After printing and heating,the materials can use to make clothes and scarf.
3) Pigment Ink:For all kinds of textile fabrics.
Specifications:
1. Low cost
2. High productivity
3. Dye Sublimation system
4. Directly print on textile material
Description:
Speed and precision perfectly reflected
With 1800 DPI highest precision and 120 sqm/hour fastest speed
Adopt high speed industrial KYOCERA printhead
X-ais use liner motion motor and magnetic grating
Y-axis use Fuji AC servo motor
Applications:
Interior Home Decoration: Print on polyester fabric to make windows curtain and Tablecloth, sheets and so on.
 |
 |
 |
After Sales Service:
1. With one year warranty and lifelong technical support.
2. Offer Video and operation manul,and the professional technical staff online guidance.
3. Guarantee prompt warranty service for main parts repairment and replacement by international courier
How To Order:
Inquriy-------Quotation-------Order-------Production-------Quality Control-------Packing-------Shipping-------Delivery
