Polyester Inkjet Textile Printing Machine Digital Tension Control Electro Thermal Heating

Polyester Inkjet Textile Printing Machine Digital Tension Control Electro Thermal Heating

Polyester Inkjet Textile Printing Machine Digital Tension Control Electro Thermal Heating

Product Details:

Place of Origin: China
Brand Name: SAER
Certification: CE
Model Number: CSR 2200

Payment & Shipping Terms:

Minimum Order Quantity: One set
Packaging Details: Non fumigation wooden package
Delivery Time: Within 5 Working days after the payment arrived
Payment Terms: T/T
Supply Ability: 1000 sets / month
Contact Now
Detailed Product Description
Product Name: Digital Textile Printer Suitable Fabric Type: Knitted Or Woven Cotton,linen,silk,wool,chemical Fiber,nylon.oxford Etc
Application: Indoor & Outdoor Type: Inkjet Printer
Print Head: 3 Epson 4720 Ink Supply Mode: Continuous Ink Supply
Max Resolution: 1400dpi Condition: New
Color Mode: CMYK Max Materials Width: 2.4m

polyester printing machine sublimation flag printer machine 2M

Quick Detail:

240cm All-in-one Printer system(with the function of print and heat,can not seperate to two individual parts)and one filter fan,one stop solution.

Description:

1· Electro thermal Heating
2· Intelligent PID Temperature Control
3· Digital Tension Control
4· Feeding and Taking up Are synchronous
5· Vacuum Fan Delivery Is Controllable
6· Quick Tail Gas Treatment
7· Convenient to Maintain
8· Easy to Set up and Operate
9. Easy to load the media in and out oven during your machine working
10. Easy to open the caver to clean inside of oven
11. Special clutch to control the feeding up system working or stop , it’s easy for you loading the roll materials.
12. Adopting the most advanced thermal energy technology low power consumption, saves electricity and conserve energy costs.

Applications:

Printed directly on Oxford fabric, printed fabric can be used to make shift tents
Polyester Inkjet Textile Printing Machine Digital Tension Control Electro Thermal Heating

Specifications:


Product name Economic CSR2200 Sublimation Machine
Item No. CSR 2200
Printhead EPSON 4720
Number of Printhead Three
Print Resolution 1800dpi
ink sublimation ink/pigment ink.
Maximum Print Width 2000mm
Print Speed 3 pass 360x1800DPI 65m²/h
4 pass 720X1200DPI 45m²/h
6 pass 720x1800DPI 35m²/h
Printer Head height Adjustable 1.5~6mm
Ink Type Sublimation Ink, pigment ink
Color dual CMYK
Ink Supply System Continuous Ink Supply System
Media Maximum Width 2000mm
Feeding mode Automatic feeding and taken-up system
weight Sublimation machine net weight 800kg, gross weight 1000kg
power consumption sublimation heater Directly dye sublimation heater 3500w
printer printer 1000w
printer power AC210-230v 50-60HZ 16A
temperature 25-35°C
humidity 35-65%(non-condensing)


Competitive Advantage:

• Suitable for small lot, Personality, Diversity Printing, Without Limit Of Quantity.
• The printed image color is bright and vivid with nice color gamut.
• High speed
• It is simple and leave out heat transfer process, one person can operates with high efficency and short time.
• Low cost and no need of any kind transfer paper, liner breaking the highest costs performance

Polyester Inkjet Textile Printing Machine Digital Tension Control Electro Thermal Heating

Specifications:

Save Money   No need to use transfer paper
Save Time      No need to perform heat transfer step
Save Space    No need to keep a workplace for a heat transfer

Produtc Service :

1. This machine has One year warranty .
2. We Support Oversea technical service and with all life techincal support.

How To Order:
Inquriy-------Quotation-------Order-------Production-------Quality Control-------Packing-------Shipping-------Delivery
Polyester Inkjet Textile Printing Machine Digital Tension Control Electro Thermal Heating
