Wide Format Digital Textile Printing Machine With Dual CMYK

Wide Format Digital Textile Printing Machine With Dual CMYK

    • Wide Format Digital Textile Printing Machine With Dual CMYK
    • Wide Format Digital Textile Printing Machine With Dual CMYK
  • Wide Format Digital Textile Printing Machine With Dual CMYK

    Product Details:

    Place of Origin: Shanghai, China
    Brand Name: SAER
    Certification: CE Certification
    Model Number: CSR3200

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Non fumigation wooden package
    Delivery Time: 15 working days after get your payment
    Supply Ability: 50 sets per month
    Contact Now
    Detailed Product Description
    Printing Color: Dual CMYK Printing Maintenance: Easy
    Printing Ink: Eco-friendly Sublimation Ink & Pigment Ink Printing Resolution: High
    Printing Format: 2m, 3.2m , Can Customize Printing Quality: Excellent
    Printing Technology: Inkjet Printing Efficiency: High
    High Light:

    Dual CMYK Textile Printer

    ,

    2m Digital Textile Printing Machine

    Product name: Sublimation printer Custom Full Color Digital Flag Printing Machine





    Machine working speed:













    Printing resolution and speed



    Resolution(dpi) speed
    360*1800dpi(3 pass) 85m2/h

    720*1220dpi(4 pass) 65m2/h

    720*1800dpi(6 pass) 45m2/h





    Product Features:



    1. Direct Print image into fabric

    2. This machine with print and heat in one machine Save price and save place.

    3. It is adopt EPSON printhead with high precision.

    4. This machine max print width 3.2m





    Machine Specifications:



    Model CSR3200
    Print head Piezo technology, Epson print head
    Ink Sublimation Ink,Reactive ink and Pigment Ink
    Color Mode Dual CMYK
    Nozzles (180 nozzles*8 lines)*3 heads
    Print Head Height 1.5mm/6mm(adjustable)
    Ink Supply Mode Continuous Ink Supply
    Max Material Width 3300mm



    Max Printing Width 3200mm
    Roll Owter Diameter 3 Inch
    Max Weight For Roll Material 100KG
    Interface USB3.0
    RAM 128M
    Printer Power 380V
    Power Direct Dye Sublimation Heater 3500W
    Printer 2000W
    Environment temperature 20-32 degree
    Weight 1120KG













    Applications:

    Interior Home Decoration: Print on polyester fabric to make windows curtain and Tablecloth, sheets and so on.
    Outside: Advertising materials to make flag,roll up banner, act fast show and so on.



    Competitive Advantage:



    • Lower investment cost,3.2 meters width machine more usability
    • One time molding mechanism design, reflect the stability and reliable of textile printer

    • High speed
    • Automatic high precision feeding system, make sure that the exact stationary into the cloth long figure carefree
    • Using the sublimation ink, compatible with the advertising industry in backlit mode. more environmental, more beautiful effect.







    Automatic feeding and collecting structure:




    1,Intelligent infrared heater and fan drying system;
    2,The machine through different quality tests is stable and competent enough for mass production requirement.
    3,No Pinch roller, let the fabric no wrinkle and print smoothly

    4,Keep the fabric good air permeability after sublimation

    5,Printing groove designed specially for fabric printing to collect waste ink and keep

    fabric clean.

    6,Patented ink tanks keep ink supply constantly.







    ONYX Rip Software:


    1. Onyx rip sofware easy to complete the Photos / vector data,replacement of RGB / CMYK,and can easily to achieve color change.

    2.Colorful color replacement function can easily reproduce the required color.



    Our Support:



    (1) 12-month warranty

    (2) Free techinical traning

    (3) On-site service

    (4) Sample free

    (5) Lifetime maintenace


    After Sales Service:



    1. With one year warranty and lifelong technical support.

    2. Offer Video and operation manual, and the professional technical staff online guidance.

    3. Guarantee prompt warranty service for main parts repairment and replacement by international courier







    FAQ:



    1) How can I place order?
    A: Contact us about your order details,we will prepare the PI .

    2) How can I pay you?
    A: uaually we accept T/T , Western Union,Money Gram.

    3) How about the after-sale service?
    A: Machine guarantee 12 month, printheads are no guarantee. We supply the on line technology even machine out of guarantee.

    4) If I buy the machine, can you supply the ink, material, etc also?
    A: Yes sure, please use the Original ink, it's better for the printer maintance, we can supply the relate material also.

    5) I want to open a new business, can you give me some ideas?
    A: Yes, we can, please tell me what products you want to make, and your request, we can offer you some projects.



    Usage:



    Wide Format Digital Textile Printing Machine With Dual CMYK 0
