Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed

Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed

    • Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed
    • Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed
  • Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed

    Product Details:

    Place of Origin: Shanghai,China
    Brand Name: SAER
    Certification: CE Certification
    Model Number: SR 3200

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Non fumigation wooden pakage
    Delivery Time: Whithin 5 working days after receive the payment
    Payment Terms: T/T, Western Union
    Supply Ability: 100 sets per month
    Contact Now
    Detailed Product Description
    Product Name: Sublimation Heater Automatic Grade: Automatic
    Color & Page: Multicolor Dimensions(L*W*H): 4350mm*1310mm*1230mm
    Usage: Textile Color Fixation Machine Working Width: 3.2m
    Color Mode: Dual CMYK Take Up Working Method: Directly Out Or Roll To Roll
    Available Printer: Mutoh,Mimaki And Any Piezo Printers

    Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed





    Combine With:



    3.2m Heat Sublimation Machine include one 3.2m heater and filter fan



    Products Features



    a.Work together with Textile Printer,print and heat synchronized.

    b.Working temperature can reach 300°C,can quickly dry the ink.

    c.Print speed can reach 100m/h.



    Specifications



    Product Name

    Direct Dye Sublimation heater

    Model

    SR 3200

    Blackbody Tube Working Model

    Far Infrared

    Mainly Use

    Dry ink,appear and fix the image color

    Power

    6.5kw(include filter fan)

    Maximum Width

    3300mm

    Heat Tube Dimension

    3400mm

    Working Temperature Control

    Room temperature ~250°C

    Temperature Control Method

    PID

    Tension Control

    3kg(optional counterweight to control tension)

    Maximum Speed

    0~2800mm/min

    Filter Fan Speed

    0~300m³/h

    Filter Fan Power

    400W

    Working Voltage

    220v 50hz

    Machine size

    4350mm*1310mm*1230mm(not include filter)

    Net Weight

    625kg(not include filter)

    Gross Weight

    1025kg(Include filter and package)

    Operating mode

    Instrument control, manual, automatic opera



    Advantage



    1. Exhaust without any smell, good environment need.
    2. Normal temperture for exhaust , no dangerouse for hot air out.
    3. High Efficiency cold system to make sure the exhaust temperture less then 25 Degree.
    4. Drawer-type device in a timely manner to facilitate the replacement of activated carbon to ensure that the emission of harmful gases.

    5. Can united any piezo printers



    Applications



    1) 100% Cotton Fabrics ( Such as cotton canvas , cotton bags, cotton bed sheets etc. )
    2) Fashion apparel,clothing accessories( such as scarves,ties etc)
    3) Sportswear and swimwear fabrics ,Home Textile Fabrics(eg. curtains,bed sheets,towels,table cloths and furniture cloth)
    4) Car decorations ,Flags and banners
    5) T-shirts and specialty textiles; wall decoration; umbrellas, bags, shoes, hats, toys, ribbon, etc.;



    After Sales Service



    1. One year warranty

    You can discuss opration and maintenance with our technician online support by skpe,whatsapp etc,

    2. Free exchange of new components

    Our quality is guarranteed 100%,the spare parts can be replaced within one year free of charge,except for the print head and some damageable parts.

    3. Free online consultation

    The technician will keep online,no matter whatever technical questions that you may have,you would get a satisfactory answer.



    Product Details:



    Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed



    Heated Samples:



    Multicolor Automatic Dye Sublimation Equipment Roll To Roll High Speed
