Shanghai Color Digital Supplier Co., Ltd.
Professional Digital Textile Printing Equipment & Relevant Materials General Supplier
 |
| Place of Origin: | CHINA |
| Brand Name: | SAER |
| Certification: | CE CERTIFICATE |
| Model Number: | CSR 2200 |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiation |
| Packaging Details: | without fumigation wooden package |
| Delivery Time: | 5-8 DAYS AFTER PAYMENT |
| Payment Terms: | T/T |
| Supply Ability: | 1000 sets / month |
| Type: | Inkjet Printer | RAM: | 128M |
|---|---|---|---|
| Usage: | Cloths Printer | Automatic Grade: | Automatic |
| Warranty: | 1 Year | Keywords: | Sublimation Machine |
| Product Name: | Sublimation Textile Heat Transfer Printer | Feature: | High Speed |
| Ink: | Pigment Ink Sublimation Ink | Print Head: | Epson High Presicion |
| Resolution: | 1800DPI | Ink Type: | Sublimation,textile Pigment Ink |
| Printing Material: | Polyester | Net Weight: | 800kg |
| Condition: | New | ||
| High Light: | digital fabric printer,continuous inkjet printer |
||
| Product Model | CSR 2200 |
| Printhead | Piezo technology, Three Epson printer heads |
| Ink | Environmental Sublimation ink, Pigment Ink optional |
| Color | Dual KCMY |
| Printing Media | Soft roll to roll |
| Fabric Type | Knitted or woven cotton,linen,silk,wool,chemical fiber,nylon.oxford,cotton etc |
| Medium Transfer | Continous Transport Automatic Fabric Feeding & Taking-up |
| Nozzles | (180 nozzles x 8 lines ) x3 heads |
| Printer head higher | 15mm / 6mm ( Adjustable ) |
| Ink supply model | Continuous ink supply |
| Ink Volume | 2000ML Volume ink,automatic ink detector |
| Max materials width | 2200mm |
| Printing width | Maximum 210 cm |
| Printing Speed | Production Mode 45㎡/hour |
| Image Data Format | TIFF,JPEG |
| Rip Software | ONYX |
| Roll diameter | 3 Inch |
| Maximum weight for roll material | 100kg |
| Interface | USB 3.0 |
| RAM | 128M |
| Printer power | AC210-230V / AC220-240 Adaptive 50/60Hz |
| Sublimation machine | AC220-240V. 16A. 50/60Hz |
| Power consumption | Direct dye sublimation heater 3500w |
| Printer 1000w | |
| Temperature | 20-32°C(68 – 89.6 ℉) |
| Humidity | 40-60% RH |
1· Electro thermal Heating
2· Intelligent PID Temperature Control
3· Digital Tension Control
4· Feeding and Taking up Are synchronous
5· Fan Delivery Is Controllable
6· Quick Tail Gas Treatment
7· Convenient to Maintain
7· Easy to Set up and Operate
9. Easy to load the media in and out oven during your machine working
10. Easy to open the caver to clean inside of oven
11. Special clutch to control the feeding up system working or stop , it’s easy for you loading the roll materials.
12. Easy to change the active carbon from the filter
13. Adopting the most advanced thermal energy technology low power consumption, saves electricity and conserve energy costs.
Home Decoration: Print on polyester fabric to make windows curtain and Table cloth,sheets and so on also can make Wall Stickers.
This machine prints directly on fabric without heating transfer process. It can work continuously for 24 hours without corrugated.
1. Stable and continuous printing, using strong mechanical to ensure printing high resolution and stabilitIty
2.Adopt professional feeding system and fit to textile without tension. Stable feed
resolution and stability material, make sure printing process
3. No need platemaking and fit to flag and scroll
4. Using constant temperature coloration box, fast temperature rising. Good tightness to guarantee the even temperature
5. Environmental smoke exhaust filter system to handle smoke efficiently and make clean work shop
6. Use open ink supply system which is compatible to more brand sublimation ink
1) How can I place order?
A: Contact us about your order details,we will prepare the PI .
2) How can I pay you?
A: uaually we accept T/T , Western Union,Money Gram.
3) How about the after-sale service?
A: Machine guarantee 12 month, printheads are no guarantee. We supply the on line technology even machine out of guarantee.
4) If I buy the machine, can you supply the ink, material, etc also?
A: Yes sure, please use the Original ink, it's better for the printer maintance, we can supply the relate material also.
5) I want to open a new business, can you give me some ideas?
A: Yes, we can, please tell me what products you want to make, and your request, we can offer you some projects.
