Product Details:
|
| Product Name: | Direct Textile Printer | Suitable Fabric Type: | Knitted Or Woven Cotton,linen,silk,wool,chemical Fiber,nylon.oxford Etc |
|---|---|---|---|
| Resolution: | 360dpi,720dpi,1080dpi,1440dpi | Print Head: | 2 PCS Epson DX5 |
| Ink Supply Mode: | Continuous Ink Supply | Application: | Indoor & Outdoor |
| Character: | No Pinch Roller | Material Transfer: | Automatic Feeding & Take-up |
| Color Mode: | CMYK | Masupplyx Materials Width: | 2.4m |
| Highlight: | fabric printing equipment,textile printing equipment |
||
Quick Detail:
One 320cm all-in-one printer (print and heat function together)
One filter fan for collect waste air
Description:
1. High Resolution
High resolution of 1440 dpi, to achieve the resolution as photo’s
2. High Printing Speed
With 2 PCS Epson DX5 print head, can get high quality printing of 40㎡ / h
3. High Stability
Mechanism design of industrial grade circuit design is through the evaluation of tens of thousands of customers’ use, with super high stability and very low failure rate
4. Humanized Design
Intelligent design: automatic material take-up and release system work stability, automatic drying system and automatic ink feeding system, to achieve higher intelligence.
5. Low Cost
Use the original ink with the machine and print head, to achieve the use of low cost
6. Continuous upgrading of software
The use of the global current original software, to ensure the sustainable upgrading of software technology.
Applications:
Sublimation digital textile printer has been used most field such as advertisement printing textile digital printing, flag making, carpet digital printing, windows curtain digital printing and interior decoration printing and even t-shirt,swimming or sports wear printing.
Specifications:
| Product Model | CSR 3200 |
| Printhead | Using 2 Epson DX5 Print head,180 nozzles * 8 lines, high quality to 1440dpi |
| Ink | Environmental Sublimation ink, Pigment Ink optional |
| Color | Dual KCMY |
| Printing Media | Soft roll to roll |
| Printer head higher | 15mm / 6mm ( Adjustable ) |
| Ink supply model | Continuous ink supply |
| Ink Volume | 2000ML Volume ink,automatic ink detector |
| Max materials width | 3300mm |
| printing width | Maximum 320 cm |
|
Print mode and speed |
Mode speed |
| Draft 2pass 40m² / h 720 * 360dpi | |
| 3pass 32m² / h 360 * 1080dpi | |
| Standard 4pass 22m² / h 720 * 720dpi | |
| 6pass 18 m² / h 720 * 1080dpi | |
| High Quality 8pass 12 m² / h 720 * 1440dpi | |
| Image Data Format | TIFF,JPEG |
| Rip Software | ONYX |
| Drying System | Infrared drying system |
| Roll diameter | 3 Inch |
| Maximum weight for roll material | 100kg |
| Interface | USB 2.0 |
| RAM | 128M |
| Printer power | AC220-240V / AC220-240 Adaptive 50/60Hz |
| Sublimation machine | AC220-240V. 16A. 50/60Hz |
| Power consumption | Direct dye sublimation heater 6000w |
| Printer 5500w | |
| Temperature | 20-32°C(68 – 89.6 ℉) |
| Humidity | 40-60% RH |
| Packing Dimension(L * W * H) |
Printer system: 4560*1180*1560(MM) 8.4CBM Filter: 620X550X1050(MM) 0.36CBM |
| Weight |
Net Weight : Printer:788kg Filter:55kg Gross Weight : Printer: 986kg Filter:72kg |
Competitive Advantage:
• Lower investment cost,3.2 meters width machine more usability
• One time molding mechanism design, reflect the stability and reliable of textile printer
• High speed
• Automatic high precision feeding system, make sure that the exact stationary into the cloth long figure carefree
• Using the sublimation ink, compatible with the advertising industry in backlit mode. more environmental, more beautiful effect.
Save Money No need to use transfer paper
Save Time No need to perform heat transfer step
Save Space No need to keep a workplace for a heat transfer machine
Rip Software:
1. Easy to complete the Photos / vector data,replacement of RGB / CMYK,and can easily to achieve color change.
2.Colorful color replacement function can easily reproduce the required color.
Produtc Service :
1. This machine have one year warranty .
2. We are support oversea service .
3. This machine has technical support in all of life.
How To Order:
Inquriy-------Quotation-------Order-------Production-------Quality Control-------Packing-------Shipping-------Delivery
|
|
|
