Product Details:
|
| Type: | Inkjet Printer | RAM: | 128M |
|---|---|---|---|
| Usage: | Cloths Printer | Automatic Grade: | Automatic |
| Warranty: | 1 Year | Keywords: | Sublimation Machine |
| Product Name: | Sublimation Textile Heat Transfer Printer | Feature: | High Speed |
| Ink: | Pigment Ink Sublimation Ink | Print Head: | Epson High Presicion |
| Resolution: | 1800DPI | Voltage: | AC210-230v |
| Condition: | New | ||
| Highlight: | digital textile printing equipment,cmyk printing machine |
||
1. Image quality is rival compared to Japanese similar piezoelectric EPSON printer;
2. three head standard equipped with intelligent infrared drying system;
3. Products structure designed aim at printing sublimation printer;
4. Whole machine tested strictly, stable and reliable so it can meet the needs of mass productions.
More details
1. Constant temperature heating box
rapidly heating, good leakproofness ensure the temperature constant
2. Green smoke extraction filtration system
filter and sublimation smoke efficiently, keep the environment clean
3. open ink-supply system
Compatible with many brands of sublimation ink, easily to control the printing cost.
| Product Model | CSR 2200 |
| Printhead | Piezo technology, Three Epson printer heads |
| Ink | Environmental Sublimation ink, Pigment Ink optional |
| Color | Dual KCMY |
| Printing Media | Soft roll to roll |
| Fabric Type | Knitted or woven cotton,linen,silk,wool,chemical fiber,nylon.oxford,cotton etc |
| Medium Transfer | Continous Transport Automatic Fabric Feeding & Taking-up |
| Nozzles | (180 nozzles x 8 lines ) x3 heads |
| Printer head higher | 15mm / 6mm ( Adjustable ) |
| Ink supply model | Continuous ink supply |
| Ink Volume | 2000ML Volume ink,automatic ink detector |
| Max materials width | 2200mm |
| Printing width | Maximum 210 cm |
| Printing Speed | Production Mode 45㎡/hour |
| Image Data Format | TIFF,JPEG |
| Rip Software | ONYX |
| Roll diameter | 3 Inch |
| Maximum weight for roll material | 100kg |
| Interface | USB 3.0 |
| RAM | 128M |
| Printer power | AC210-230V / AC220-240 Adaptive 50/60Hz |
| Sublimation machine | AC220-240V. 16A. 50/60Hz |
| Power consumption | Direct dye sublimation heater 3500w |
| Printer 1000w | |
| Temperature | 20-32°C(68 – 89.6 ℉) |
| Humidity | 40-60% RH |
Home Decoration: Print on polyester fabric to make windows curtain and Table cloth,sheets and so on also can make Wall Stickers.
This machine prints directly on fabric without heating transfer process. It can work continuously for 24 hours without corrugated.
1. Stable and continuous printing, using strong mechanical to ensure printing high resolution and stabilitIty
2.Adopt professional feeding system and fit to textile without tension. Stable feed
resolution and stability material, make sure printing process
3. No need platemaking and fit to flag and scroll
4. Using constant temperature coloration box, fast temperature rising. Good tightness to guarantee the even temperature
5. Environmental smoke exhaust filter system to handle smoke efficiently and make clean work shop
6. Use open ink supply system which is compatible to more brand sublimation ink
1.We have professional engineers who have more than 6years, is very patient to support you if you have any questions;
2.We can support you 24hous for online training and guide you step by step;
3.If you need to support you in your local shop,our engineers have passport,we can suppor you for overseas training.
4.We have factory , welcome to learn more here,we can discuss and guide face by face.
packing and shipping
Transpotation
by sea transaction
FAQ
Q: Are you a manufacturer or trading company?
A: Yes, we're the professional factory with trading department
Q: What is the MOQ?
A: 1 Unit
Q: What's your payment term?
A: T/T before shipment
Q: How long is the warranty time?
A:Our factory provide one year warranty (except print head). Beyond one year, only charge at cost.
Q: What's the delivery time?
A: Normally is 3-7 days after deposit
Q:.where can I buy the spare parts and inks?
A:Our factory also provide spare parts and inks, you can buy from our factory directly or other suppliers in your local market.
