Product Details:
|
| Color&Page: | Multicolor | Usage: | T-shirt Printing |
|---|---|---|---|
| Plate Type: | Flatbed Printer | Type: | Inkjet Printer |
| Condition: | New | Place Of Origin: | Shanghai, China (Mainland) |
| Automatic Grade: | Automatic | Warranty: | 1 Year |
| Highlight: | t shirt screen printing machine,garment printing machine |
||
Product name: Customized t-shirt printing machine direct to garment printing with A3 size
Product description:
1, Easy operate, do not need plate-making, Direct print picture on light/ dark t shirts.
2, Different from Heat press machine, the samples with good air permeability.
3, Support White & Color Print in One pass.
4, Never lose color even wash by hundred times.
5, Very Cheap for personalized T shirt customized
6, 8 colors CMYK+WWWW/CMYK+FMFY+WW/CMYK+OR BL+WW. It can print light colors and dark colors T-shirts.
Machine speed:
| Speed | Production models | A3 size 4pass | Dark color fabric 1min.14s |
| Light color fabric 58s | |||
| precision | A3 size 6pass | Dark color fabric 1min.52s | |
| Light color fabric 1min.27s |
Parameters:
| Items | Technical Parameters | ||
| Model |
CSR2200(R) |
||
| Print head | Print head | Ricoh GH2220 head | |
| QTY | 8 pieces | ||
| Ink | Color | CMYK+WWWW/CMYK+FMFY+WW/CMYK+OR BL+WW | |
| Ink type | Import pigment ink, good fastness,bright color | ||
| Ink supply | Negative pressure supply ink | ||
| Tray | Standard configuration | Optional configuration | |
| Tray size | 380*480mm | 600*1200mm | |
| Tray Numbers | 3 | 1 | |
| Interface | USB | ||
| Computer system | CPU>2GHz, 64 bit CPU, RAM>8G, Windows7,Windows10 | ||
| Working environment | temperature:20℃-30℃, humidity:55％-70％ | ||
| Power supply | 210-230VAC 50/60 HZ 16A | ||
| Software | Rip software | ||
| Machine Dimension | 2065*1705*1240mm | ||
| Machine Weight | 260kg | ||
