Product Details:
|
| Max Print Width: | 3200mm | Resolution: | 360-1800dpi |
|---|---|---|---|
| Working Type: | Roll To Roll | Print Head Amount: | Epson 4720 *3 Pieces |
| Color Mode: | Dual CMYK | Ink Supply Model: | Continuous Ink Supply |
| Rip Software: | Maintop 5.3 Rip Software Or Onyx Optinoal | Ink: | Dye Sublimation Ink / Pigment Ink |
| Material: | Polyester,Cotton,Wool And Silk Textile Material | Automatic Grade: | Automatic |
| Highlight: | mimaki digital printing machine,digital fabric printer,continuous inkjet printer |
||
Digital Printing Machine with high speed and resolution for fabric trade show displays
Specifications:
|
Model |
CSR 3200 |
| Brand | SAER |
|
Print head |
Piezo technology, 3 Epson 4720 print head |
|
Ink |
Dye sublimation ink / Pigment ink |
|
Color model |
Double 4 Color(CMYK) |
|
Print Head |
(180 nozzles x 8 lines ) x3 pieces of head |
|
Printer head higher |
1.5mm / 6mm ( Adjustable ) |
|
Ink supply model |
Continuous ink supply |
|
Max materials width |
3300mm |
|
Max printing width |
3200mm |
|
Maximum weight for roll material |
100kg |
|
Interface |
USB 2.0 |
|
RAM |
128M |
|
Printer power |
AC220-240V./AC220-240Adaptive 50/60Hz |
|
Sublimation machine |
AC220-240V. 16A. 50/60Hz |
|
Power consumption |
Direct dye sublimation heater 3500W |
|
Printer 5500w |
|
|
Temperature |
20-32°C |
|
Humidity |
40-60% Non-condensing |
|
Weight |
Net Weight :875kg Gross Weight : 1000kg |
Details of machine :
Description:
Print head:
Three Epson 4720 Print heads, faster speed, longer head life time. Feather printing function available, print heads correction and counterpoint are more easy. Intelligent print head cleaning service, supply safe and convenient print head cleaning and protection function.
Guid Rail:
Using HIWIN mute guide rail. Germany IGUS silent drag chain make your printing environment more quit ．
X axis and Yaxis:
X axis and Y axis are using AC servo motors.
Advantages :
Application :
Warranty & Services
(1) One year of warranty time.
(2) About the after-sales service:
A. If the printer has problem, the client can take a picture or video to the technician.
B. The technician will teach the client to fix and operate the printer through the internet.
C.We will ask the client to send back the board which is wrong to check it.
D.The technician is full of experience, and the sales also keep in touch with the client.
