Automatic Roll To Roll Digital Textile Printing Machine 3.2m Max Print Width

Automatic Roll To Roll Digital Textile Printing Machine 3.2m Max Print Width
Automatic Roll To Roll Digital Textile Printing Machine 3.2m Max Print Width Automatic Roll To Roll Digital Textile Printing Machine 3.2m Max Print Width

Large Image :  Automatic Roll To Roll Digital Textile Printing Machine 3.2m Max Print Width

Product Details:
Place of Origin: Shanghai of China
Brand Name: SAER
Certification: CE Certification
Model Number: CSR3200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Non fumigation wooden package
Delivery Time: 14 days after get the payment
Payment Terms: T/T, Western Union
Supply Ability: 100 sets per month

Automatic Roll To Roll Digital Textile Printing Machine 3.2m Max Print Width

Description
Condition: New Automatic Grade: Automatic
Color & Page: Multicolor Usage: Fabric Printing
Resolution: 360-1440dpi Max Print With: 3.2m
Highlight:

sublimation printing machine

,

digital textile printing equipment

,

cmyk printing machine

Roll To Roll Sublimation Printing Machine Automatic Textile Digital Printing Machine



Product name: Textile digital printing machine / Sublimation Printing Machine





Product features:



1. Far Infrared Blackbody Tube Radiation Electro thermal Heating, our tuble can work at least 10000 hours.




2. Our machine have excellent heat insulation, can save more power for you.




3. Easy to load the media in and out oven during your machine working




4. Blackbody tuble have more thermal efficiency







5. Intelligent PID Temperature Control



6. Feeding and Taking up Are synchronous




7. Taking up can choose roll to roll .







8. Quick Tail Gas Treatment




9. Convenient to Maintain




10. Easy to Set up and Operate







11. Easy to open the caver to clean inside of oven




12. Easy to change the active carbon from the filter











Adopting the most advanced thermal energy technology low power consumption, saves electricity and conserve energy costs.



Specification:



Product parameter
Product name Sulimation textile printing system
Model CSR3200
Include One set of whole machine and one filter
Ink model Sublimation ink
Available color Dual CMYK
Print head Piezo technology,2 Epson DX7 print head
Max material width 3300mm
Max printing width 3200mm
Print head high control 1.5mm/1.6mm(adjustable)
Media type Polyester
Ink feeding system 4 color  mode:400cc  cartriage*2color  800cc/color
Roll outer diameter 3 inch
Max weight for roll material 100kg
Head cleaning Automatic/Manual
RAM 128M
Printer power AC380V(Adaptive)  50/60Hz±1Hz
Heater power consuption 3500KW
Printer power consuption 7.5KW
Weight 890KG
Operation environment 20-23oC   Humidity:40-60% (non-condensing)





Machine printing resolution and speed:



Resolution Speed
720*360dpi(2 pass) 40m2/h
360*1080dpi(3 pass) 32m2/h
720*720dpi(4 pass) 22m2/h
720*1080dpi(6 pass)  18m2/h
720*1440dpi(8 pass) 12m2/h







Filter Specification:



Power 550w
Package size 60*55*108CM(0.382CBM)
Net Weight 64kg
Gross Weight 80kg
Working Voltage 220-240V 50HZ
Input Air Temperature ﹥200℃
Out Air Temperature ﹤25℃
