Product Details:
|
| Plate Type: | Roll To Roll | Type: | Digital Printer |
|---|---|---|---|
| Automatic Grade: | Automatic | Color Model: | Dual CMYK |
| Usage: | Fabric Printing | Ink: | Sublimation Ink / Disperse Ink |
| Max Printing Width: | 3.2m | ||
| Highlight: | cloth printing machine,inkjet printer |
||
Product name: Digital printing on fabric / Sublimation digital printer for feather flag
Product features:
1. Far Infrared Blackbody Tube Radiation Electro thermal Heating, our tuble can work at least 10000 hours.
2. Our machine have excellent heat insulation, can save more power for you.
3. Easy to load the media in and out oven during your machine working
4. Blackbody tuble have more thermal efficiency
5. Intelligent PID Temperature Control
6. Feeding and Taking up Are synchronous
7. Taking up can choose roll to roll .
8. Quick Tail Gas Treatment
9. Convenient to Maintain
10. Easy to Set up and Operate
11. Easy to open the caver to clean inside of oven
12. Easy to change the active carbon from the filter
Adopting the most advanced thermal energy technology low power consumption, saves electricity and conserve energy costs.
Specification:
| Product parameter | |
| Product name | Sulimation textile printing system |
| Model | CSR3200 |
| Include | One set of whole machine and one filter |
| Ink model | Sublimation ink |
| Available color | Dual CMYK |
| Print head | Piezo technology,2 Epson DX7 print head |
| Max material width | 3300mm |
| Max printing width | 3200mm |
| Print head high control | 1.5mm/1.6mm(adjustable) |
| Media type | Polyester |
| Ink feeding system | 4 color mode:400cc cartriage*2color 800cc/color |
| Roll outer diameter | 3 inch |
| Max weight for roll material | 100kg |
| Head cleaning | Automatic/Manual |
| RAM | 128M |
| Printer power | AC380V(Adaptive) 50/60Hz±1Hz |
| Heater power consuption | 3500KW |
| Printer power consuption | 7.5KW |
| Weight | 890KG |
| Operation environment | 20-23oC Humidity:40-60% (non-condensing) |
Company History:
2001 year
Shanghai Color Digital Supplier established at Shanghai City .
2004 year
The first SR sublimation textile heater was came into the market.
2013 year
The first direct digital textile printer with heat system was came into the market by our company in the world.our company obtained seven patent.
Based on the concept of quality first and services in the future,we will spend more energy to R & D new product and technology,provide our customers with high quality products and perfect after-sales service, development with customers, to create the future.
Printing resolution and speed |
Resolution speed |
| 720x360dpi (2pass) 40m²/h | |
| 360x1080dpi(3pass) 32m²/h | |
| 720x720dpi(4pass) 22m²/h | |
| 720x1080dpi(6pass) 18 m²/h | |
| 720x1440dpi(8pass) 12 m²/h |
