Product Details:
|
| Product Name: | Flag Printing Machine | Maximum Resolution: | 1440dpi |
|---|---|---|---|
| Print Head: | Epson DX5 * 2 PCS | Ink Supply Model: | Continous Ink Supply |
| Rip Software: | Onyx | Ink Type: | Dye Sublimation Ink,pigment Ink,reactive Ink |
| Media Type: | Polyester,Cotton,Wool,Mixed,Linen And Silk Textile Material Etc | Color Management: | Superior ICC Profile |
| Printing Interface: | Computer Control The Output Directly | Media Handle: | Automatic Feeder,automatic Take Up |
| Media Processing: | Roll To Roll + Auto Feeding + Auto Roll Up | Media Heating: | Pre-heating & Post Color Fixation |
| Minimum Resolution: | 360dpi | Ink Clor: | C,M,Y,K |
| Maximum Speed: | 40㎡ / Hour | Maximum Media Breadth: | 2.4m |
| Max Print Breadth: | 2.2m | Print Head Cleaning: | Automatic Clean |
| Highlight: | banner printing machine,textile digital printing machine |
||
1440 DPI Epson Head Flag Printing Machine For Polyester,Cotton,Silk
Introduce
Consist of 2.2m integrated fabric printing system and filter fan, sublimation printing type, printed material can use indoor and outdoor, can stand sunshine and no fade, also can be washed.
Usage Field:
Serve solutions for small production, sample making ,designer ideas and training areas
Product Features:
Technical Specifications:
| Brand Name | SAER |
|
Machine Model |
CSR 2200 |
|
Print head technology |
Piezo technology |
| Print Head | Epson DX5 |
|
Color mode |
Double four color(C,M,Y,K) |
|
Nozzles |
(180 nozzles x 8 lines ) x2 heads |
|
Print head higher |
1.5mm / 6mm ( Adjustable ) |
|
Ink supply model |
Continuous ink supply |
|
Maximum materials breadth |
2400mm |
|
Maximum printing breadth |
2200mm |
|
Roll diameter |
3 Inch |
|
Maximum weight for roll material |
100kg |
|
Interface |
USB 2.0 |
|
RAM |
128M |
|
Print Power |
AC100-120V./AC220-240V(Adaptive) 50/60Hz |
|
Power consumption |
Direct dye sublimation heater 3500W |
|
Printer 100w |
|
|
Temperature |
20-32°C |
|
Humidity |
40-60% Non-condensing |
| Available Media | Polyester,cotton,silk,linen,blending,knitting Fabric |
| Ink Type | Dye Sublimation,Reactive and Pigment |
| Media Handle | Automatic feeder,automatic take up |
| File Format |
TIFF,JPEG,PDFand other common image formats Control software Chinese version and English Version |
|
Weight |
Net Weight : 764kg Gross Weight : 886kg |
| Rip Software | Onyx |
| Working Process | Windows XP / Windows 7 |
| Gross Weight | 886kg |
| Net Weight | 646kg |
| Package Size | 3350*1070*1550mm |
Printing Resolution And Speed:
| Resolution | speed |
| 720 x 360dpi (2pass) | 40m²/h |
| 360 x 1080dpi(3pass) | 32m²/h |
| 720 x 720dpi(4pass) | 22m²/h |
| 720 x 1080dpi(6pass) | 18 m²/h |
| 720 x 1440dpi(8pass) |
12 m²/h |
Ink and Material it can use
a. Sublimation Ink for Coated polyester fabric.
b. Reactive Ink for polyester,cotton,silk,linen,cotton and linen blended fabric,weave fabric etc
c. Pigment Ink for all kinds of textile fabrics.
After Sales Service:
1. One year warranty
2. Provide 24 hours online service.
when you the first time operate the machine,our engineer will be online to guide you.
When your machine have any problem, our engineer will help you to solve it through remote control.
3. If necessary,we can send you new spare parts.
Application:
Home Decoration:Print on polyester fabric to make windows curtain and Table cover,bed sheets and so on,also can make Wall Stickers.
Outside Using :Advertising materials to make flag,pop up banner,tear drops banners,and so on,no fade and can stand sunshine and rain.
Machine Details:
