Product Details:
|
| Type: | Stand Alone And Connect Printer | Max Work Size: | 1.8m |
|---|---|---|---|
| Work With Printer: | Mimaki, Mutoh, Roland And Other Printer | Voltage: | 220V 50 HZ |
| Mainfuction: | Fixation And Bright Color | ||
| Highlight: | digital printing machine,digital printing machines |
||
Roll to Roll 1.8 M Direct Textile Printing Dryer Heater Machine For Beach Flag
Product Feature
1. Far Infrared Blackbody Tube Radiation.
2. Electro thermal Heating.
3. Intelligent PID Temperature Control.
4. Digital Tension Control.
5. Feeding and Taking up Are synchronous.
6. Vacuum Fan Delivery Is Controllable.
7. Quick Tail Gas Treatment.
8. Roll to roll Work Way.
9. Heating Tube Size 1900mm .
Product Techincal Data
|
Power |
3.8KW |
|
Working Width |
1800MM |
|
Blackbody Tube Working Model |
Far Infrared |
|
Heat Tuble Dimension |
2220MM |
|
Working Temperture |
100 to 250 °C |
|
Tension |
0 to 1.2Kg |
|
Working Voltage |
220~240V 50HZ |
|
Weight |
330Kg |
|
Certification |
CE Certificated |
|
Package |
High intensity standard carton package Non Fumigation |
|
Available Printer |
Mimaki, Roland , Mutoh and any Piazo Printer |
Product Advantages
1. Easy to load the media in and out oven during your machine working
2. Easy to open the caver to clean inside of oven
3. Special clutch to control the feeding up system working or stop , it’s easy for you loading the roll materials.
4. Easy to change the active carbon from the filter
5. Adopting the most advanced thermal energy technology low power consumption, saves electricity and conserve energy costs.
6. No sell . No Polluet.
7. Passed CE
Product Picture
|
Our Filter Fans Specificaton:
|
| Power | 360W |
| Working Voltage | 220~240V 50HZ |
| Package Size | 620X565X1100mm |
| Weight | 60 Kg |
| Input Air temperature | >200 ℃ |
| Out put Air temperature | <25 ℃ |
| Filter Medium | Active Carbon |
| Certification | CE Certificated |
Filter Fans Picture
Product Field
To Produce Flags, Color Banner, cloth printing etc
LOW COST
IT IS SIMPLE AND LEAVE OUT HEAT TRANSFER PROCESS ONE PERSON CAN OPERATES WITH HIGH EFFICENCY AND SHORT TIME.
LOW COST AND NO NEED OF ANY KIND TRANSFER PAPER ,LINER BEAKING THE HIGHEST COSTS PERFORMANCE.
Product Service
1. This machine have one year warranty .
2. We are support oversea service .
3. This machine has technical support in all of life.
